Journal article
Microstructural development in asymmetric processing of tantalum plate
Journal of electronic materials, Vol.34(12), pp.1521-1525
12/2005
Handle:
https://hdl.handle.net/2376/115057
Abstract
Sputtered tantalum (Ta) and TaN are employed as barrier layers in modern integrated circuits to enable reliable use of Cu as an interconnect material. The directional properties of sputtering Ta can result in nonuniform film thicknesses (from heavily textured plate) and unpredictable sputtering rates (from plates with through thickness texture gradients). This results in film thicknesses larger than necessary because of the sputtering being unpredictable. This presentation reports on an effort to increase textural and grain size uniformity in Ta by deforming the plate under conditions that simulate asymmetric rolling. This is accomplished by using a channel die configuration with uneven friction on the top and bottom plates so that a strong shear component is added to the plane strain condition enforced by the channel dies. Results indicate a trend towards less severe texture banding and more uniform structure in the plate processed by asymmetric friction conditions.
Metrics
4 Record Views
Details
- Title
- Microstructural development in asymmetric processing of tantalum plate
- Creators
- D Field - School of Mechanical and Materials Engineering Washington State University Pullman WAJ Yanke - School of Mechanical and Materials Engineering Washington State University Pullman WAE Mcgowan - School of Mechanical and Materials Engineering Washington State University Pullman WAC Michaluk - Michaluk and Associates Gilbertsville CA
- Publication Details
- Journal of electronic materials, Vol.34(12), pp.1521-1525
- Academic Unit
- Mechanical and Materials Engineering, School of
- Publisher
- Springer-Verlag; New York
- Identifiers
- 99900547697101842
- Language
- English
- Resource Type
- Journal article
